A quilted padded cover folded once so both its face and its padded cross-section show.

A padded cover cut open to expose the closed-cell foam core between its outer shell and lining.

Cases stacked four high in a baggage holding area, the bottom case compressed under the load.

A · Shell Covers

Cover Padded 28

Name: Cover Padded 28
Brand: Checkline
SKU: A-06
Price: 58.00 USD
Availability: InStock

The padded build in the large cut. The size that spends the most time at the bottom of a stack.

USD 58

One-time purchase. No subscription.

Free standard shipping over USD 49.

Not sure it fits?

How it is built

The same three-layer padded construction as the 24 in the large cut: 300D woven outer, 4 mm closed-cell EVA core, taffeta lining, quilted on a 60 mm grid.

Suits these shells

Hard shell, polycarbonate: Flexes under load and springs back. Takes surface scuffing more than cracking.
Hard shell, ABS: Stiffer and more brittle than polycarbonate. Corners are the usual failure point.
Soft side, fabric: Absorbs impact but scuffs and tears. Zippers and handles take the strain.

Specification

Fits case height: 69–76 cm · 27–30 in
Material: 300D polyester outer, 4 mm closed-cell EVA core, taffeta lining, 60 mm quilt grid
Fits case height: 69–76 cm / 27–30 in
Foam core: 4 mm closed-cell EVA
Quilt: 60 mm grid, lock-stitched
Added weight: Roughly 610 g over a bare case
SKU: A-06

Where those figures come from

Foam layer thickness: Measured on the panel centre of the finished cover with a dial thickness gauge at 1 N contact force, five points averaged per sample, three samples.
Foam density: Closed-cell EVA, apparent density measured per sample block at 23 °C and 50 % relative humidity, three samples averaged.
Corner impact test: Free fall from 1.0 m onto a rigid steel plate, case loaded to 15 kg, impact on the lower shell corner, five repeats per sample, three samples, conducted at 23 °C.
